Solis S6-EH3P10K02-NV-YD-L 10kW 3-Phase Hybrid Inverter
Brand: Solis
● In stock — ready to deliver
10kW Three-Phase Hybrid Solar Inverter for residential and commercial systems
97.6% Maximum Efficiency for efficient solar energy conversion
Dual MPPT Technology with 200–850V MPPT voltage range
40–60V Battery Support with 220A charge/discharge current
IP66 Protection with 200% backup peak power for 10 seconds & 5 years warranty
- Official manufacturer warranty on this product
- Delivery available across Bangladesh
- Installation & after-sale support available
Product details
Solis 10kW 3-Phase Hybrid Inverter Price in Bangladesh
The Solis S6-EH3P10K02-NV-YD-L 10kW Hybrid Inverter is designed for efficient three-phase solar power generation and reliable low-voltage battery backup. It helps optimize solar energy usage, supports energy storage, and provides a dependable power solution for residential and commercial applications. Choose Cyber Energy BD for quality solar power solutions in Bangladesh.
Solis S6-EH3P10K02-NV-YD-L Hybrid Inverter Full Specification
Model : | S6-EH3P10K02-NV-YD-L |
Inverter Type : | Three-Phase Hybrid / Energy Storage Inverter |
Rated Output Power : | 10 kWh |
Start-Up Voltage : | 160 V |
MPPT Voltage Range : | 200–850 V |
Number of MPPTs : | 2 |
Maximum PV Input Strings : | 4 |
Maximum Input Current : | 20 A |
Battery Type : | Li-ion / Lead-acid |
Battery Voltage Range : | 40–60 V |
Maximum Charge/Discharge Current : | 220 A |
Rated Grid Output Power : | 10 kWh |
Rated Grid Frequency : | 50 / 60 Hz |
Maximum Output Current : | 15.2 A |
Backup Peak Power : | 200% of rated power for 10 seconds |
Backup Switching Time : | 10 ms |
Maximum Efficiency : | 97.6% |
Protection Rating : | IP66 |
Cooling : | Intelligent Fan Cooling |
Operating Temperature : | -40°C to +60°C |
Maximum Operating Altitude : | 4000 m |
Dimensions : | 430 × 660 × 305 mm |
Weight : | 42 kg |
